Quick loading, high travel speeds and the ability to load and dump on the run yield fast cycle times, allowing Cat Wheel Tractor-Scrapers to consistently deliver high productivity at the lowest cost per ton.
Open Bowl Scrapers
180° Curb-to-Curb Turning Width
11.8m
Scraper Capacity - Heaped
18.4m³
Maximum Depth of Spread
540.0mm
24/7 Customer Support
Questions? We're here to help.
Learn MoreGenuine Cat Parts
Extend the life of your equipment with Genuine Cat Parts and Service.
Learn MoreService Agreements
Maximise uptime. Improve productivity. Reduce costs.
Learn MoreOverview
The principal choice for moving material on an earthmoving site is the Cat®
627 Wheel Tractor-Scraper. Twin-powered for high rollingresistance and steep grades, this machine is engineered to work effectively in a wide range of conditions and material types. Whether traveling through sand, clay, or shot rock, it’s specifically designed to fit an earthmover’s needs for today‘s and
tomorrow’s work.
Specifications
General
- 180° Curb-to-Curb Turning Width11.8m
- Scraper Capacity - Heaped18.4m³
- Maximum Depth of Spread540.0mm
- Maximum Depth of Cut315.0mm
- Width - Cut3.14m
- Top Speed - Loaded53.9km/h
- Fuel Tank Refill Capacity - Scraper1272.0l
- Scraper Capacity - Struck13.0m³
- Overall Width3.57m
- Overall Shipping Height4.03m
Attachments
