Simple Operation
Mechanical controls provide simple and reliable operation. Push button keypads for feeder system and cable-operated ground drive controls allow operation from either side of the machine.
Heavy Duty Screed
The Weiler-designed 1,360 kg screed delivers outstanding mat quality and a paving range of 2.3 m to 4.4 m. Weiler’s patented end gate design allows quick adjustments for extension height and joint matching.
Precise Control
Screed mounted upper and lower 228 mm augers and independent control of each side of the delivery system provide precise material control for variable-width paving. Flow gate style cut-off doors and reversible augers and conveyors limit spillage between passes.
Durable Components
Highway class chains, conveyor and auger bearings and direct-drive conveyor head shaft provide long-term reliability. Replaceable components maximize the life of the paver.
Power to Push
Cat® C3.4B Tier 4 engine with 74 hp (55 kW) powers the best-in-class 1778 mm track length undercarriage through a 2-speed hydrostatic drive. Optional 356 mm performance, poly pads and standard 125 mm track chain pitch optimize the ride with a 250 fpm (76 mpm) max transport speed.
Fast Service
Remote grease lines, spray down system with four (4) coiled hoses located on each corner of the paver, five (5) engine access doors and Caterpillar dealer service and support keep your machine up and running with limited machine downtime.
Specifications
Operating Weight | 7,348 kg | ||
Standard Paving Range | 2.3 - 4.4 m | ||
Length | 3,835 mm | ||
Width | 2,489 mm | ||
Height | 1,778 mm | ||
Truck Clearance | 457 mm | ||
Auger Diameter | 228 mm | ||
Screed Weight | 1,360 kg | ||
Main Plate Width | 419 mm | ||
Extension Plate Width | 228 mm | ||
Screed Heat | Electric - 4 elements | ||
Vibration | 1 x 2,500 VPM | ||
Auger Speed | 110 RPM | ||
Engine | Cat ® C3.4B Tier 4F | ||
Horsepower | 74 HP (55.2 kW) No DEF | ||
Fuel Capacity | 98.4 L | ||
Hopper Capacity | 7 tons | ||
Transport Speed | 76mpm | ||
Hydraulic Tank Capacity | 113 L |
